Product description

Modern MTB Design

Tapered fork steerer tubes*, quality components including a 1x drivetrain* with clutch-equipped rear derailleurs, thru-axle hubs*, internal cable routing (including dropper seatpost) and an integrated chainstay protector give aspiring trail riders room to grow. *on select models

Off-Road Control

New geometry is optimized for confident trail riding and two different wheel sizes (27.5 or 29-inch) depending on frame size. The geometry is also designed for front suspension with either an 80mm or 100mm fork depending on frame size. All models have clearance for high-volume tires (up to 2.4-inch) for traction and grip on technical terrain.

Light and Durable

All-new ALUXX aluminum frame features updated shaping and a lighter overall weight for improved performance on off-road terrain.

Frame	ALUXX-grade aluminum
Fork	Giant SXC32-3 RL, coil spring, 1.5" tapered alloy steerer, 15x110mm thru-axle XS,S: 80mm (27.5) S, M, L, XL: 100mm (29)
Shock	N/A
Handlebar	Giant Connect Trail, 31.8mm
Grips	Giant Sole-O
Stem	Giant Sport, 7-degree
Seatpost	Giant Contact Switch Core dropper, remote XS, S: 100 travel / 30.9 x 350mm, M-XL: 120 travel / 30.9 x 400mm
Saddle	Giant ErgoContact Trail
Pedals	platform
Shifters	Shimano CUES U6000, 1x10
Front Der.	N/A
Rear Der.	Shimano CUES RD-U6000
Brakes	Tektro HDC M275, hydraulic Tektro rotors, [F]180mm, [R]160mm
Brake Levers	Tektro HDC M275
Cassette	Shimano CUES, LinkGlide, 10-speed, 11x48
Chain	KMC X11
Crankset	ProWheel Charm, [27.5] 32t, [29] 30t, 52.5mm chainline 32t
Bottom Bracket	cartridge
Rims	Giant GX03V 27.5 or 29, alloy, double wall, 21mm IW
Hubs	alloy, sealed bearing, [F] 15x110 thru axle, [R] 12x142 thru-axle
Spokes	stainless
Tires	Maxxis Rekon 27.5x2.4" or Maxxis Rekon Race 29x2.4", 60 TPI, wire bead
Extras	2.4" max tire size, max chainring 32t
